WATT VAR PF TRANSDUCER
For efficient & trouble free operation of the vital power transformers used for power distribution, it is highly essential to monitor & control its Oil & Winding temperatures. Closely monitoring & keeping a check on these temperatures also prevents accidental breakdowns of these transformers.
Static design, no moving parts.
Quick Response Time.
Output independent of load impedance.
Computerized Circuit design.
Components have high thermal withstand capacity & can survive extreme tropical atmospheric conditions.
Stable output even in case of wide power supply fluctuations (for self-powered & Aux. Powered transducers).
Galvanic isolation between input / output /auxiliary power supply.
Standard DIN Rail mounting, cabinets.
| WATT VAR PF TRANSDUCER |
|---|
| MODEL | ||
|---|---|---|
| WATT TRANSDUCER (WT – 08) |
VAR TRANSDUCER (VAR – 08) |
PF TRANSDUCER (PFT – 08) |
| Type | ||
|---|---|---|
| 2 or 3 ELE. Uni or BI-Direcional | 2 or 3 ELE. Uni or BI-Direcional | 2 or 3 ELE. 1 ELE |
| Rated Input | ||
|---|---|---|
| 0-1A or 0-5A 0-63.5 or 0-110V / 100V AC Through CT, PT | 0-1A or 0-5A 0-63.5 or 0-110V / 100V AC Through CT, PT | 0-1A or 0-5A 0-63.5 or 0-110V / 100V AC Through CT, PT |
| Measurement Range | ||
|---|---|---|
| WATT (IMP & EXP.) | WATT (LEAD & LAG) | 0.5LEAD-0-0.5LAG |
| Continuous Overload Capacity | ||
|---|---|---|
| X 2 (I), X 1.2 (V) | X 2 (I), X 1.2 (V) | X 2 (I), X 1.2 (V) |
