MFT-05 TRANSDUCER
For efficient & trouble free operation of the vital power transformers used for power distribution, it is highly essential to monitor & control its Oil & Winding temperatures. Closely monitoring & keeping a check on these temperatures also prevents accidental breakdowns of these transformers.
Static design, no moving parts.
Quick Response Time.
Output independent of load impedance.
Components have high thermal withstand capacity & can survive extreme tropical atmospheric conditions.
Stable output even in case of wide power supply fluctuations (for self-powered & Aux. Powered transducers).
Galvanic isolation between input / output /auxiliary power supply.
Standard DIN Rail mounting, cabinets.
Cal. check facility.
On site programmable any parameter.
| MFT-05 TRANSDUCER |
|---|
| MODEL |
|---|
| MFT-05 |
| Input Configuration |
|---|
| 3-Ph 4-Wire or 3-Ph 3-Wire |
| Configurable Parameters | ||||
|---|---|---|---|---|
| i) R Current | ii) Y Current | iii) B Current | iv) RY Voltage | v) YB Voltage |
| vi) BR Voltage | vii) Average Phase to Neutral voltage | viii) Freq. | ix) PF | x) Bipolar Watt |
| xi) Unipolar Watt | xii) Bipolar Var | xiii) Unipolar Var | xiv) VA | |
| FSD |
|---|
| 50 to 150 % of full scale |
| Rated Input |
|---|
| 0-1A or 0-5A 0-63.5 or 0-110VAC Through CT, PT |
