ANNUNCIATOR
ACCORD Digital Panel Meters designed in view of the typical atmosphere and tropical conditions in the Indian Industry / Electrical Sub-stations.
Aesthetically designed lightweight compact enclosure.
μ-Controller based logic.
Opto-isolated inputs & outputs.
Reliable & long-life push buttons for TEST, ACCEPT & RESET operations.
System can be designed as per custom requirements.
Facia Windows with long life super bright LEDs.
Trip or Non-Trip selection for every channel.
NO or NC annunciation selectable independently for every channel.
Sequence of operation is selectable
Front removable facia for easy changing of legend.
| ANNUNCIATOR |
|---|
| Rated Auxiliary Supply | ||
|---|---|---|
| 85 – 250V AC/DC. | ||
| Response Time | ||
|---|---|---|
| Less than 25 milliseconds on request. | ||
| Burden on Auxiliary Supply | ||
|---|---|---|
| Less than 1W per window. | ||
| Fault input contacts | ||
|---|---|---|
| NO or NC (site selectable), potential free | ||
| Interrogation Signal | ||
|---|---|---|
| 24VDC (for ensuring proper detection). 12VDC can also be supplied if insisted. | ||
